OpenSSL: Generate CSR & sign it for valid certificates (Kibana | Opensearch Dashboard| Wazuh Dashboard)

One common challenge when setting up Kibana, Wazuh Dashboard, or OpenSearch Dashboard is transitioning from self-signed certificates to publicly signed ones, ensuring browsers recognize your SSL connection as secure.

---

This write up describe how to achieve it using Openssl :

• Create a temporary key:

openssl genrsa -out my-key-temp.pem 2048

• Convert Private Key to PKCS#8 Format:

openssl pkcs8 -inform PEM -outform PEM -in my-key-temp.pem -topk8 -nocrypt -v1 PBE-SHA1-3DES -out my-private-key.pem

Save the key my-private-key.pem as it will be used in the configuration

• Create the openssl.cnf file where you specify the domain information:

[ req ]
default_bits       = 2048
distinguished_name = req_distinguished_name
req_extensions     = v3_req
prompt             = no

[ req_distinguished_name ]
countryName         = Country Name (2 letter code)
stateOrProvinceName = State or Province Name (full name)
localityName        = Locality Name (eg, city)
organizationName    = Organization Name (eg, company)
commonName          = Common Name (e.g. server FQDN or YOUR name)

[ v3_req ]
subjectAltName = @alt_names

[ alt_names ]
DNS.1 = domain.com
DNS.2 = *.domain2.com

• Generate the CSR certificate:

openssl req -new -key my-private-key.pem -out my-server.csr -config openssl.cnf

• Send the CSR to be signed or sign it if you have access to the CA as follows:

openssl x509 -req -in my-server.csr -CA /Path/to/Ca/root-ca.pem -CAkey /Path/to/Ca/root-ca.key -CAcreateserial -out myserver.pem -days 3650 -extfile openssl.cnf -extensions v3_req

That should sign and generate the certificate myserver.pem

---

---

Now that you have the certificate myserver.pem and the key my-private-key.pem, You can use them as follows:

Wazuh Dashboard:

• Copy the certificate under /etc/wazuh-dashboard/certs

• Specify the certificates within /etc/wazuh-dashboard/opensearch_dashboards.yml

server.ssl.key: "/etc/wazuh-dashboard/certs/my-private-key.pem"
server.ssl.certificate: "/etc/wazuh-dashboard/certs/myserver.pem"

• Modify the permissions and ownership of the certificates:

chown -R wazuh-dashboard:wazuh-dashboard /etc/wazuh-dashboard/
chmod -R 500 /etc/wazuh-dashboard/certs/
chmod 440 /etc/wazuh-dashboard/certs/my-private-key.pem /etc/wazuh-dashboard/certs/myserver.pem

• Restart the Wazuh dashboard service:

systemctl restart wazuh-dashboard

Opensearch Dashboard:

• Place the certificates under /etc/opensearch-dashboards/certs


• Specify them within /etc/opensearch-dashboards/opensearch_dashboards.yml

server.ssl.key: "/etc/opensearch-dashboards/certs/my-private-key.pem"
server.ssl.certificate: "/etc/opensearch-dashboards/certs/myserver.pem"

• Modify the permissions and ownership of the certificates:

chown -R opensearch:opensearch /etc/opensearch-dashboards/
chmod -R 500 /etc/opensearch-dashboards/certs/
chmod 440 /etc/opensearch-dashboards/certs/my-private-key.pem /etc/opensearch-dashboards/certs/myserver.pem

• Restart the Wazuh dashboard service:

systemctl restart opensearch-dashboard

Kibana:

• Copy the certificate under /etc/kibana/certs

• Specify them within /etc/kibana/kibana.yml

server.ssl.certificate: /etc/kibana/certs/myserver.pem
server.ssl.key: /etc/kibana/certs/my-private-key.pem

• Modify the permissions and ownership of the certificates:

chown -R kibana: /etc/kibana/certs
chmod -R 770 /etc/kibana/certs

• Restart the service:

systemctl restart kibana
